1. Identify and detect the three main components of an air flow meter. The key to identifying and detecting an air flow meter is to master the characteristics and inspection methods of its three core components. When identifying hot wires (or hot films), the hot wire type is usually a spiral shaped core digging thin metal wire placed in the air modification channel; The hot film type is a heating resistor film made on a ceramic substrate. A multimeter can be used for testing to determine if there is damage by measuring its resistance value and comparing it with the standard value, or observing whether its voltage changes accordingly with changes in engine operating conditions. 2. Temperature compensation resistor This device is usually close to a hot wire or hot film, and appears thicker than a hot wire. It is a common resistance element that compensates for the effects of changes in intake temperature. The detection method is to use a multimeter to measure its resistance value and compare it with the standard temperature resistance curve at different temperatures. The control circuit is integrated into the control box of the air flow meter, consisting of a circuit board and electronic components, and has multiple pins for connection and communication. The detection needs to check whether the power supply is normal. A multimeter can be used to measure the voltage of the electric pin insulation pin, or a diagnostic instrument can be used to read the output signal to see if it meets the requirements of the engine operating conditions. 2. What are the testing steps for an air flow meter?
The detection method of air flow meter is as follows:
1. It can be judged by measuring the output voltage data w
2、 It can be determined by measuring the output voltage of the sensor.
3、 Remove the plug of the air flow meter while the engine is running and observe the changes in the engine to determine. More information about Sakura Fiber is as follows:
1. It can be determined by measuring the output voltage data of the engine during operation: the dynamic signal voltage at the plug signal end is 0.8-1.4V when the engine is idling, and the voltage signal can approach 4V when accelerating to full negative grinding load. If it is not within this range, it may be due to damage to the air flow sensor itself or due to dirt. Cleaning is sufficient.
2、 It can be determined by measuring the output voltage of the sensor: using a multimeter to detect a general voltage value of 5V, blowing air into the sensor with a hair dryer. If the voltage changes with the magnitude of the incoming air volume, it is considered normal; If there is no change or minimal variation, it indicates that the flowmeter is faulty and needs to be replaced.
3、 When the engine is running, unplug the plug of the air flow meter and observe the changes in the engine to determine: if there is a slight change in the fault phenomenon, it indicates that the air flow meter is good; Fault disappearance: indicates that the flow meter signal has deviation and is not damaged; Fault persists: This indicates that the air flow meter has long been damaged or the wiring is poor.
3. How to check the air flow meter?
1、 Resistance test: The resistance test in this project is an auxiliary test, mainly to detect the conductivity of the wiring harness, to confirm that the wiring harness is unobstructed, w
