What are the measurement ranges of turbine flow meters?
1、 Turbine flowmeter is based on the electromagnetic induction generated by the rotation of turbine blades inside the flowmeter to measure the flow rate. It can measure both liquids and gases, and is very sensitive. The diameter for measuring liquids is generally DN4- DN200, and for measuring gases it is generally DN20- DN300;
2、 Turbine flowmeter measures liquids with a very small diameter and good economy. The units are generally m3/h (cubic meter/hour), L/min (liter/base silver minute), etc. It has instantaneous flow display and cumulative flow display;
3、 The measurement range corresponding to different diameters of turbine flow meters is: liquid measurement: (unit of measurement: m3/h): DN4: 0.04--0.25; DN6：0.1---0.6； DN10：0.2---1.2； DN15：0.6---6； DN20：0.8---8； DN25：1---10； DN32
1.5---15； DN40：2---20； DN50：4---40； DN65：7---70； DN80：10---100； DN100：20---200； ..... Gas measurement: (unit: m3/h): DN20:5-40; DN25：7.2---60； DN32：12---100； DN40：18---150； DN50：30---300； DN65：50---420； DN80：70---600； DN100：120---1000； ..... For more detailed information, please refer to the technical article on the website of Shandong Qiangsheng Automation Technology Co., Ltd.... Www.qszdh. com
2. What does the measuring range of the flowmeter mean by 0.4-4m ³/h, and how many gallons is it?
Each type of instrument has its own measuring range, which is its specification. The measurement range of the chaotic flow meter is 0.4-4m ³/h, which means that the liquid volume per search hour is 0.4-4 cubic meters. If this liquid is water, it would weigh between 400 kilograms and 4 tons.
3. Determination of r
The range of electromagnetic flowmeter is closely related to its type and application conditions.
. The range and flow velocity characteristics of full tube and non full tube states are different: for full tube electromagnetic flow meters, the inner diameter range is wide, from DN40 to DN300. The slag collapse ratio can reach 1:120, and the flow velocity range is wide, from 0.1m/s to 12m/s, providing great measurement flexibility. In non full pipe conditions, the flow velocity measurement range is limited to 0.05-10m/s, suitable for circular pipes with diameters ranging from DN100 to DN6000mm, and the width of rectangular pipes does not exceed 6m. This type of flowmeter pays special attention to measurement under non full pipe conditions. As a professional manufacturer of electromagnetic flow meters, Tangshan Kaixun Technology focuses on the research and development, production, and sales of intelligent flow meters. Its products have high precision, high stability, and grinding reliability. They can customize different calibers according to specific customer needs, including electromagnetic flow meters ranging from DN15 to DN1000+, which are particularly suitable for measuring industrial media. If you have any questions about electromagnetic flow meters, you can consult them, and they will provide detailed answers based on your questions to help you gain a deeper understanding of this technology.4. Flow range of vortex flowmeter
The flow range of vortex flowmeter is mainly determined by the sensor diameter and fluid properties. The larger the diameter, the wider the measurable flow range.
. The conventional liquid measuremen
