SILVER Coriolis Mass Flow Meter PDF: Technical Specifications Reference Library Guide
Quick Answer: This reference library helps engineers and buyers match SILVER Coriolis mass flow meter models to pipe size, flow range, fluid type, pressure, and temperature. The series covers DN03 to DN150 with mass flow accuracy from 0.1 to 0.2 percent of rate. You can download the SILVER CMF series PDF datasheets at flow-meter.com.au.
What This Reference Library Covers
Silver Automation Instruments keeps the Coriolis mass flow meter datasheets in one place for desalination plants, fuel oil terminals, chemical dosing systems, gas lines, and food beverage processes. Each PDF datasheet contains accuracy data, pressure rating, temperature limits, wetted material, output options, installation length, and order code. You do not need a login to view the technical reference library at flow-meter.com.au. Select the SILVER CMF model that matches your process, then request a quote by sending the parameters from your site.
Model Selection by Pipe Size and Flow Range
Pick the meter size from the actual pipe DN, not from a guess. The SILVER CMF series covers DN03, DN06, DN10, DN15, DN25, DN40, DN50, DN80, DN100, DN125, and DN150. A DN15 model handles 0 to 1500 kg/h for many liquids. A DN25 model covers 0 to 5000 kg/h. A DN50 model goes up to 20000 kg/h for water like fluids. Every SILVER CMF model measures mass flow, volumetric flow, density, and temperature at the same time.
If you measure diesel in a 25 mm line, start with the SILVER CMF DN25. For a 50 mm line with raw water at 40 bar, use the SILVER CMF DN50 with 316L stainless steel wetted parts. For concentrated syrup at 2000 kg/h, a DN15 or DN25 can work depending on viscosity and pressure drop. Send us your pipe size, flow range, and fluid, and a technical sales engineer will confirm the model.
Technical Specifications That Matter in Procurement
Mass flow accuracy is 0.1 percent or 0.2 percent of rate depending on the model. Repeatability is 0.05 percent. Density accuracy is 0.0005 g/cm3 on most sizes. Process temperature range is -50 °C to 200 °C for standard models. High temperature options extend to 350 °C. Pressure rating is 16 bar standard, with 40 bar and 100 bar options on request. Wetted material is 316L stainless steel, with Hastelloy C22 for aggressive fluids. SILVER CMF meters carry ATEX Zone 1 and Zone 2 approvals for hazardous areas.
Output options include 4-20 mA HART, pulse, frequency, and RS485 Modbus RTU. The 4-20 mA HART output is common for PLC and DCS integration in water plants and oil terminals. Pulse output works for batching and custody transfer. Modbus RTU supports SCADA systems in Southeast Asia and the Middle East. One meter can deliver mass flow, density, and temperature on a single cable. The single cable setup reduces wiring time and panel space. The local display shows kg/h, t/h, density in g/cm3, and temperature in °C. Operators can change units without a laptop.
Fluid Examples and Real Applications
A desalination plant in Oman uses the SILVER CMF DN50 to dose antiscalant and measure brine concentration. A paint manufacturer in Indonesia selected the DN15 for solvent blending at 120 kg/h. A dairy plant in Australia applies the DN25 for milk fat measurement and CIP chemical flow. A gas distributor in Nigeria measures LPG with a DN40 high pressure model. These are standard S
Installation Notes for Engineers
SILVER Coriolis mass flow meters do not require straight pipe runs like electromagnetic or vortex meters. You can mount them close to an elbow or pump. The meter must be full of liquid during measurement. For gas measurement, keep the process pressure above the vapor pressure of the fluid. For liquids with entrained gas, install the meter at a low point or use a higher back pressure. For high viscosity fluids above 100 cP, check the pressure drop before selecting the size. Viscosity changes affect the flow range. A 500 cP fluid may require one size larger than a 1 cP fluid at the same kg/h.
Zero calibration should be done at no flow with the meter full and at process temperature. Most engineers skip zero calibration on the bench and then wonder why the low flow reading drifts. We have seen this issue on customer sites many times. The SILVER CMF display menu includes a zero calibration function. You can also do zero calibration from a HART handheld communicator. Standard process connection is ANSI or DIN flange. Tri Clamp connections are available for food and beverage lines. Threaded connections are available for DN03 to DN15.
How to Download the PDF Datasheets
Go to flow-meter.com.au and open the Coriolis mass flow meter product page. The technical reference library section lists the SILVER CMF datasheet PDF for each size. Each PDF shows the flow range table, accuracy curve, dimensional drawing, wiring diagram, and order code. Buyers can use the order code to request a formal quotation. No email registration is required to download the PDF.
FAQ
Which SILVER CMF model fits a DN25 diesel line at 1200 kg/h?
Use the SILVER CMF DN25. Standard pressure rating 16 bar is enough for most transfer pumps. If the pump head exceeds 16 bar, request the 40 bar option.
Can the SILVER CMF measure gas mass flow?
Yes. SILVER CMF meters measure gas mass flow in kg/h. For low density gas below 5 kg/m3, send us the operating pressure and temperature because signal strength becomes small.
What output is best for PLC integration?
4-20 mA HART is the standard choice. Pulse and RS485 Modbus RTU are also available. One meter can output mass flow, density, and temperature at the same time.
Does the SILVER CMF work with high viscosity fluids?
Yes for most fluids up to 500 cP and beyond. Pressure drop rises with viscosity. Send us your viscosity in cP, flow rate in kg/h, and pressure budget in bar. We will check the size.
How can I get a quote with a PDF datasheet?
Send your pipe size in DN, flow range, fluid name, density or viscosity, pressure in bar, and temperature in °C to Silver Automation Instruments. You can call us at +86-25-68650347, use WhatsApp +86-25-52155837, or send WeChat message to +86 15365082610. You can also submit the parameters on flow-meter.com.au. A quote with PDF datasheet goes back within one business day.
Silver Automation Instruments supplies Coriolis mass flow meters from China to end users and distributors in Australia, Southeast Asia, Latin America, Africa, and the Middle East. Send us your pressure in bar, temperature in °C, pipe size in DN, and flow range in kg/h. We will reply with a SILVER CMF model, price, and PDF datasheet within one business day.
