What flow meter is better for measuring steam flow?
Steam flowmeter measurement can generally use vortex flowmeter, mainly for gas measurement instruments.. This flowmeter is based on the principle of Karman vortex street. When the fluid flows through a vertically inserted triangular cylindrical generator, an ordered vortex street will be generated behind it. The frequency of these vortex streets is proportional to the flow velocity of the fluid. By detecting the number of these vortex streets, the flow velocity of the fluid can be calculated, and the volumetric flow rate can be calculated based on the diameter of the pipeline. Vortex flowmeter is suitable for measuring high temperature and ultra-high temperature steam because it can withstand high temperature and high pressure environments. In addition, vortex flowmeters have the characteristics of small pressure loss, large range, reliable stability, and no direct contact with the medium. However, the density of steam varies with temperature and pressure, so when measuring steam flow, it is necessary to use a balanced rubber vortex flowmeter with temperature and pressure compensation functions to ensure accurate measurement of the actual amount of steam used. In addition to vortex flowmeters, there are also differential pressure flowmeters that can be used for measuring steam flow. However, differential pressure flow meters are gradually being phased out by users due to high pressure loss, large maintenance requirements, and low accuracy levels. In contrast, vortex flowmeters have significant advantages in measuring steam flow.
2. What are the good brands for steam flow meters?
Currently, mainstream steam flow meter brands are divided in
1. Domestic brands.
Chongqing Qingtian Teke: a benchmark for domestic high-end alternatives, a leading flow meter in Southwest China, with core products covering vortex streets, orifice plates V-cone and ultrasonic flowmeter, optimized for steam high temperature and high pressure conditions, with an accuracy of ± 0.5% FS, temperature resistance of -40 ℃ to 350 ℃, and a maximum pressure resistance of 40MPa. It has integrated temperature and pressure compensation and anti vibration design, no movable parts, long service life, low operation and maintenance costs, supports 4G/5G remote transmission, explosion-proof and anti-corrosion, suitable for industries such as thermal power and chemical industry. Chongqing Chuanyi CYY: a well-known leader and listed company in domestic automation instruments, participating in the formulation of national standards. Its core products are CVM series vortex street and differential pressure flowmeters, which adopt fully cast heat dissipation design, no movable parts, temperature resistance of 550 ℃, and pressure resistance of 35MPa. It is suitable for extreme working conditions and has strong capabilities in supporting the entire industry chain and system integration. There are many after-sales outlets that can undertake steam metering solutions for large-scale projects, making it a "national brand" in the industrial steam field Xingao Technology: a representative of domestic high cost-effectiveness, focusing on vortex flow meters and integrated temperature and pressure compensation technology. Its core produ
