What are the measurement ranges of vortex flowmeters?
1、 Vortex flowmeter is a flowmeter based on the Karman vortex principle for measurement. It can measure liquids and gases, and is also very economical. The diameter is generally DN10-- DN1000. With temperature and pressure compensation, it can accurately measure gas or steam flow, and has a wide range of applications;
2、 Vortex flowmeter can only measure volumetric flow rate, usually in m3/h (cubic meters per hour), with instantaneous flow display and cumulative flow display;
3、 The measurement range corresponding to electromagnetic flow meters of different diameters is: liquid measurement: (unit: m3/h): DN15
1.2-6; DN20
1.5---10； DN25：2---16； DN32
1.8---20； DN40：2.5---25； DN50：3.5---40； DN65：7.5---70； DN80：12---130； DN100：18---160； ..... Gas measurement: (unit: m3/h): DN15:4--28; DN20：6---40； DN25：8---50； DN32：15---150； DN40：18---180； DN50：25---480； DN65：50---500； DN80：80---800； DN100：120---1200； ..... For more detailed information, please refer to the technical article on the website of Shandong Qiangqiang Automation Technology Co., Ltd.... Www.qszdh.com
2. What is the measurement range of the DN50 vortex flowmeter diameter?
From the perspective of the DN50 dry early diameter, it is a small caliber measurement, usually calculated based on the single opening point of cubic meters. Its measurement range for liquids is (0-50) m3/h, for gases is (0-300) m3/h, and for working temperatures is between (0-350) ℃.
3. What is the price of a vortex flowmeter? Lets hear what the manufacturer has to say.
The price of a vortex flowmeter depends on the specific model, and fac
1. The core influencing factor of prices is the caliber of differences, which is one of the key factors affecting prices. For example, the price of a DN50 caliber vortex flowmeter is about 6000 yuan; The price of DN200 caliber is about 10000 yuan. The larger the caliber, the higher the price usually, which needs to be further confirmed based on the model. The installation method of flange connected vortex flowmeter is more than 500 yuan higher than that of clamp connected flowmeter, and the price difference increases with the increase of caliber. For example, the DN100 flange connection may be 800 yuan more expensive than the clamp installation, while the price difference for the DN200 may reach 1200 yuan. If a third-party verification certificate is required for the verification fee, the price will be more than 1000 yuan higher than that of products without certificates, and the verification fee is related to the caliber. For example, DN50 certified products may cost 1200 yuan more, while DN200 may cost 1800 yuan more. Other factors for measuring media: Corrosive media require special materials (such as stainless steel), which are significantly more expensive than ordinary media. Anti vibration selection: High anti vibration models require special design, with a price increase of 10% -20%. Explosion proof grade: Explosion proof products have higher safety requirements, resulting in a 15% -30% increase in price. Secondly, the trade-off between price and quality. Low price risk: Vortex flowmeters are used i
