2. The difference between radar flow meters and ultrasonic flow meters.
Although radar flow meters and ultrasonic flow meters are both flow measurement devices, there are significant differences in their working principles, technical parameters, applicable scenarios, installation and maintenance, and selection logic. The specific differences are as follows:
1. The essential differences in working principles. Radar flow meters are based on microwave radar technology, which detects the surface velocity of water flow through Doppler principle and measures water level by combining FMCW (frequency modulated continuous wave) principle.. The device emits microwave signals to the water surface, receives reflected signals, analyzes frequency offset to calculate flow velocity, and then combines water level data with channel models to calculate flow rate. Its core advantage is non-contact measurement. Microwave signals are not interfered by meteorological conditions (such as rainstorm and strong wind) and can be continuously monitored all day long. Ultrasonic flow meters are divided into three types based on the propagation characteristics of ultrasonic waves in fluids: insertion type, pipe section type, and external clamp type. Insertion type/pipe section type: the sensor directly contacts the fluid and calculates the flow velocity using the velocity difference between forward and backward ultrasonic waves; External clamp type: The sensor is installed on the outer wall of the pipeline, and ultrasonic waves penetrate the pipeline wall for measurement. However, signal attenuation is significantly affected by pipeline materials (such as metal and plastic) and fl
2. Core difference in technical parameters: Radar flowmeter measurement range: effective distance 0-40 meters, flow velocity 0.1-40 meters/second, accuracy of ± 0.01 meters/second or ± 1%, water level accuracy up to ± 5 millimeters;
; Power consumption and supply: Power consumption<80mA under 12VDC power supply, supports 9-24V wide voltage, suitable for solar power supply; Protection level: IP68, can withstand outdoor humid and dusty environments, and can withstand long-term immersion without damage. Precision differentiation of ultrasonic flow meters: The accuracy of the pipe section is close to that of the radar, but the larger the pipe diameter, the higher the cost; The insertion accuracy is moderate, and the price is not affected by the pipe diameter, but the installation quality affects the results; The external clamping type has the lowest accuracy and poor stability. Power consumption and supply: The overall power consumption is higher than that of the radar, and most of them do not support wide voltage; Protection level: mostly IP65, difficult to adapt to long-term immersion environment.III. Differentiated Radar Flowmeters for Applicable Scenarios in Rivers/Open Channels: Installed above water bodies (>0.5 meters), unobstructed and stable water flow is sufficient, not affected by sediment or floating objects;
; Underground sewage well: Waterproof design suitable for humid and enclosed environments, compact structure suitable for narrow spaces, can be connected to telemetry terminal institutions to build online monitoring systems; Wilderne
