What is the difference between a vortex flowmeter and a vortex swirl flowmeter? The main difference between a vortex flowmeter and a vortex swirl flowmeter lies in their definitions. Vortex flowmeter: It is a pure source flowmeter developed and produced based on the Karman vortex principle, mainly used for flow measurement of industrial pipeline media fluids, such as gases, liquids, vapors, and other media. Its characteristics are small pressure loss, large range, high accuracy, and almost unaffected by parameters such as fluid density, pressure, temperature, viscosity, etc. when measuring volumetric flow rate under working conditions. Vortex Spiral Flow Meter: The vortex flow meter adopts the latest micro processing technology, which has the advantages of strong crack flow function, wide flow range, easy operation and maintenance, and convenient installation and use. Its main technical indicators have reached the advanced level of similar foreign products. Widely used in various industries such as petroleum, chemical, power, metallurgy, and coal for gas measurement.

2. Tianxin TDS-200B Intelligent Spiral Flow Meter User Manual: [2]

The core content of the Tianxin TDS-200B Intelligent Spiral Flow Meter User Manual is as follows:

1. Product Overview Tianxin TDS-200B Intelligent Spiral Flow Meter is a flow measurement instrument designed based on the principle of spiral vortex, suitable for flow measurement of gases or liquids.

. Its core components include the precession generator, sensors, and intelligent processing unit, which achieve high-precision measurement by detecting the vortex frequency generated by the fluid.

2. Instructions for use: The flowmeter should be installed horizonta

lly in the pipeline to avoid measurement errors caused by tilting or vertical installation.

. The installation location should be away from vibration sources, bends, or valves to ensure stable fluid flow. The length of the front and rear straight pipe sections must meet the following requirements: front ≥ 10D, rear ≥ 5D (D is the diameter of the pipeline). Wiring and debugging power supply wiring: Provide 24V DC power supply to ensure correct polarity. Shenkong Wa signal output: supports 4-20mA current signal or pulse signal output, and needs to be configured according to system requirements. Parameter setting: Set parameters such as range, unit, alarm threshold, etc. through instrument buttons or upper computer software. After the operation process is powered on, the instrument self checks and displays "READY" indicating normal operation. Input fluid parameters (density deficit, viscosity, etc.) for compensation calculation. Real time monitoring of traffic data, supporting local display or remote transmission.

III. Common faults and solutions Fault phenomenon 1: No flow display Possible reasons: power supply not connected, sensor damaged, signal line open circuit.

. Solution: Check the power connection, replace the sensor, and rewire. Possible causes of flow display fluctuation include fluid pulsation, improper installation position, and incorrect parameter settings. Solution: Add dampers, adjust installation positions, and recalibrate parameters. Fault phenomenon 3: Abnormal output signal. Possible causes include excessive load, signal interference, and module failure. Solution: Reduce load, shield interference sources, and replace output modules. 4. Maintenance and Regular Inspection: Check the cleanlines
