Which of the following statements about various flow rates in the water supply network is correct under the condition of constant water supply Answer: As the water supply can be divided into two parts: concentrated flow and flow along the line, when the water supply remains constant, the larger the concentrated flow, the smaller the flow along the line. Option A is correct. The node flow is equal to the node flow converted from the flow along the line plus the concentrated flow. Therefore, the sum of the node flow of all nodes is equal to the total water consumption of the river. Option B is incorrect. Node traffic includes centralized traffic and node traffic converted along the J-bridge line. Option C is incorrect. In a branched pipeline network, the previous pipe section bears all downstream node flow, so the calculated flow of the previous pipe section is equal to the sum of its downstream node flow, and the D term is correct.

2. Node Traffic

Node traffic, in simple terms, refers to the overall traffic aggregated on a certain network node. The size of this traffic is not affected by the direction of the traffic, and it focuses on the sum of all unit quantities passing through that node.

. In the design of water supply networks, there are various calculation methods: firstly, the length to flow ratio method can be used. The basic principle of this method is to add up all the flow along the pipeline and then divide it by half of the total length of the nodes. The formula is: Qj (node flow)=∑ flow along the line/2. Here, Qj represents node traffic, and ∑ represents the sum of all traffic along the line. Secondly, another calculation method is based on the length per capita water equivalent. This me Node traffic calculation

thod takes into account population factors, where the flow rate of the irregular reed infiltration point is equal to the per capita water distribution equivalent of the designed population at that node multiplied by the population, plus the water consumption of large users (such as factories or public facilities). The formula is: Qj=per capita water distribution equivalent * node design population+large user water consumption. Both methods are designed to accurately evaluate and allocate the flow demand of each node in the water supply network, ensuring the effective operation and fair distribution of the water supply system. In practical applications, engineers will choose appropriate calculation methods based on the specific situation and requirements of the network.

3. Hydraulic calculation of hot water network

Hydraulic calculation of hot water network is the core to ensure the balance and efficient operation of the system, and it needs to be promoted according to the principles of fluid mechanics.

1. Calculation Principle 1 The law of conservation of mass: The flow rate at all nodes needs to be balanced, and the inflow and outflow flow rates are equal.

2. The law of conservation of energy: The algebraic sum of resistance losses in each pipe section of the same closed loop is zero.

2. Calculation steps 1 Draw an axonometric diagram: clarify the pipeline direction, branch position, and equipment layout

2. Calculate the flow rate of each section: calculate the flow rate of each section based on the heat load and heat medium parameters (such as the temperature difference between supply and return water)

3. Preliminary selection of pipe diameter: Based on the flow rate
