How to install and wire Kaifeng electromagnetic flowmeter correctly?
The correct method and wiring points for installing the Kaifeng electromagnetic flowmeter are as follows:
1. Installation requirements: The installation direction and electrode position sensor can be installed vertically, horizontally, or obliquely, but it is necessary to ensure that the center line of the two electrodes is in a horizontal state to avoid measurement errors caused by uneven distribution of the medium.
. When installed horizontally, the electrode must not be located directly above the pipeline (which may accumulate gas) or directly below (which may deposit solid particles). The installation position of the medium full tube requires ensuring the flow of the medium full tube to prevent gas adsorption on the electrode or the medium not filling the tube from affecting the measurement. If the medium is not fully filled in the pipeline, the square stroke method can be used to raise the rear pipeline of the flowmeter to fill the pipeline. It is strictly prohibited to install it at the highest point or outlet of the pipeline (which is prone to gas accumulation). The length of the straight pipe section before and after the flowmeter needs to retain sufficient straight pipe sections to stabilize the flow field: the length of the front (upstream) straight pipe section: ≥ 10 times the pipe diameter (10DN). Rear (downstream) straight pipe length: ≥ 5 times the pipe diameter (5DN). If there is insufficient space on site, priority can be given to ensuring the front straight pipe section, or optimizing the flow field by installing rectifiers. Flange connection and welding flange connection type: First, spot weld the matching flange t
2. Wiring Method: Equipotential connection should be made between the flowmeter casing, the measured fluid, and the pipeline connection flange, and separately grounded to prevent static electricity or potential difference from interfering with the measurement.
. The grounding resistance should be ≤ 100 Ω, and the grounding wire should use multi stranded copper wire with a cross-sectional area of ≥ 4mm2. The signal line of the flowmeter (such as 4-20mA output, pulse output, etc.) separated from the power line should be laid separately from the power cable, with a recommended distance of ≥ 20cm to avoid electromagnetic interference. If crossing is necessary, maintain a 90 ° right angle crossing to reduce coupling interference. When installing the electrode position and flow direction perpendicular to the pipeline, the flow direction of the medium should be from bottom to top to ensure that the electrode is always immersed in the medium. When installing horizontal pipelines, the electrode position should avoid being directly above and below to prevent gas or sediment from affecting the measurement.III. Other precautions: Install supports for the straight pipe sections before and after the flowmeter according to the design requirements to p
