1. Characteristics of Rotary Flow Meter
Rotary flow meter is the most commonly used flow meter in industry and laboratory.. It has the characteristics of simple structure, straight forward viewing, low pressure loss, and easy maintenance. Rotary flow meters are suitable for measuring small flow rates through pipelines with a diameter of D<150mm, and can also measure the flow rate of corrosive media. When in use, the flowmeter must be installed on a vertically oriented pipe section, and the fluid medium flows from bottom to top through the rotor flow meter.
2. Main features of rotor flowmeter
Brand and model: Shengjie System: LZB-3WB The main features of rotor flowmeter are simple structure, intuitive design, low pressure loss, and easy maintenance.
. Rotary flowmeter is the most commonly used flowmeter in industry and laboratory. Suitable for measuring small flow rates through pipelines with a diameter of D<150mm, as well as measuring the flow path of corrosive media. When in use, the flow meter is generally installed on a vertically oriented pipe section. The fluid medium from the stove celery scraper passes through the rotor flow meter from bottom to top. The specially designed rotor flow meter can be installed horizontally or vertically from top to bottom. The rotor flowmeter consists of two components, one of which is a conical tube that gradually expands from bottom to top; The other component of the rotor flowmeter is a rotor that is placed in a conical tube and can move freely along the centerline of the tube. When measuring the flow rate of a fluid with a rotor flowmeter, the measured fluid flows in from the lower end of the conical tube, and the flow of the fluid impacts the rot
3. What are the types of rotary flow meters?
Rotary flow meters are mainly divided into two categories: glass rotors and metal tube floats.
. 1. Glass rotor flow meters are usually of the local indication type or with switch signal output, which has strong corrosion resistance and can be used to detect the flow of acids (except hydrofluoric acid), alkalis, oxidants, and other corrosive gases or liquids. They are commonly used in industries such as chemical engineering, Shennian Qi Pharmaceutical, papermaking, and sewage treatment. However, due to the fragility of glass material, it is less commonly used at critical control points. Metal tube float flow meters are usually made in the form of flow transmitters, which can be divided into electric remote transmission and on-site pointer display types according to different converters. It mainly consists of three parts: indicators (such as intelligent indicators, local indicators), floats, and conical measuring chambers. The introduction of the new generation metal tube float flowmeter into the computing system further enhances its usability and advantages, with features such as high accuracy, good repeatability, and small maintenance range.
